The wood plastic door panel production line adopts special designed SJZ92 conical twin screw extruder, uses DC speed regulator, imported world famous brand temperature controller, has the advantages of large speed regulating scope, accurate temperature control, easy and reliable operation. The auxiliary units consist of vacuum foamed stand, haul-off, cutting machine and stacker, etc. It is equipped with large forced cooling device to ensure good foamed result. The caterpillar type haul-off adopts precised reduction and frequency inverter, features reasonable structure; large hauling force and stable haul off. The cutting machine has the characteristics of reliable and precise working, accurate cutting, etc. The stacker is matched with movable trolley and special designed rubber protection shield, has the advantages of damage free to the product, easy and convenient operation, etc. The auxiliary units are able to use the PLC control, which is stable and reliable.
| Item | SJSZ 65/132 | SJSZ 80/156 | SJSZ 92/188 |
| Screw Diameters(mm) | 65mm/132mm | 80mm/156mm | 92mm/188mm |
| L/D Ratio | 22:1/25:1 | 22:1/25:1 | 22:1/25:1 |
| Output(Kg/h) | 160-200 | 250-350 | 400-500 |
| Main Driving Power(kw) | 37 | 55 | 110 |
| Heating Powder(Kw) | 4 zones, 20Kw | 5 zones, 38Kw | 6 zones, 54Kw |
Wood plastic door panel production line widely is used in making rail, passages, stairs, outdoor desk and chair, flower frame, pools etc. in addition, it can be used for indoor plate decoration , kitchen cabinet board, tray etc.
Wood plastic door panel production line
1. Special design mold
2. PLC control system
