Plastic Sheet Extruder Extrusion Extruding Machine for PP

Application

TF660 PP PS Single/Double-Layer Extrusion Line are suitable to form the sheet of PP and PS.which are the materials for forming cups,lids, dish, containers and trays with round, square and rectangular or other shapes

Design Features

01. The barrel and screw are made of high quality alloyed steel (38CrMOA1A) with high hardness, strong corrosion resistance and long operating life after nitrogen treatment.

02. The design of T-type die head brings the easy operation

03. Automatic hydraulic screen changer can keep machine continuous t production.

04. Variable frequency motor of good quality brand makes lower noisy and low energy consumption.

05. The design of spiral groove keeps calenders with good cooling effect.

06. Independent temperature controlling system of calender is more suitable for producing PP, PS sheet.

07. Can be customized according to customer' s requirements.

Raw Material:

1. can be virgin plastic material. PP, PS, PET, PLA

2. can be recyclable material, like PET Bottle Flakes, PP, PS granules

SHEET SPECIFICATION:

Usual Sheet Width: 600-800-1000mm

Usual Sheet Thickness: 0.2-2mm

APPLICATION:

1. This line is specially used for producing PET/PBT/PP/PE/HIPS/EVAOH sheet.

2. Surface Treatment: Adding some additives can improve intensity/toughness/rigidity, flame retardant, embossing, frosting, etc.

3. Application: Packing, printing, stationery, art works etc.

4. Main Products: Gift/ad/file bag/lamp cover/food packaging

FEATURES:

1. Screw with special mixing and plasticization function.

2. Coat hanger T-type die head with two throttle design enable to regulate the sheet thickness accurately.

3. Horizontal. vertical, 45 degree incline type 3 Roller Calendars may be lifted freely, sheet thickness shall be regualted by screw and pressing roller.

4. Separate roller temperature control system to control the temperature of pressing roller to gain even sheet thickness.

5. Exact slicing machine, excellent cross surface.

6. Winder with big torque motor, and it's speed and tension force adjustable.

7. Automatic metering to set the length of the products.
