Equipment Composition of Hollowness Grid Board Extrusion Line:
· Extruder: Core component, responsible for the melting and extrusion of materials.
· Mold: Determines the shape and size of the sheet.
· Cooling system: Rapidly cool and solidify the board.
· Cutting system: Cut plates as required.
· Stacking system: Automatically stacks and packages finished boards.
Specifications and models of the Hollowness Grid Board Extrusion Line:
| Extruder | SJ-150*25 | SJ-120*25 |
| Motor Power/kw | 55-75 | 37-55 |
| Molding Block Amount/P | 2 | 2 |
| Vacuum Pump Power/kw | 11 | 11 |
| Drawing Speed/m. Min-1 | 0.5-5 | 0.5-5 |
| Drawing Power/kw | 3 | 3 |
| Cutting Line Speed/m. S-1 | 44.6 | 44.6 |
| Capacity/kg. H-1 | 120-300 | 65-190 |
Product Application of the Hollowness Grid Board Extrusion Line:
1.Packaging industry: Manufacturing packaging boxes, pallets, etc., to protect goods and enhance logistics efficiency.
2. Construction industry: It is used for partition walls, ceilings, etc., featuring light weight, high strength, corrosion resistance, etc.
3. Advertising industry: Producing billboards, exhibition boards, etc., with good display effects.
4. Agricultural field: It is applied in agricultural greenhouses, fish ponds, etc., providing a good environment.
A description of the length and materials of the Hollowness Grid Board Extrusion Line：
1. Rich experience, excellent engineers
2. for PP, PC, PE plates
3. Plate width: 1220-2100mm, thickness: 2-12mm
